Permanent Magnet High-Speed
Energy-Saving Centrifugal Blower
Direct-drive Permanent Magnet Synchronous Motor · Oil-Free · 40–60% Energy Savings · 1–15kW
Why Choose HDC Blowers?
High Efficiency
PMSM high-speed motor + 3D-flow impeller saves 40–60% energy compared to traditional blowers, dramatically reducing electricity costs.
Quiet & Oil-Free
Full-ceramic ball bearings, direct drive, completely oil-free operation. Noise below 75 dB(A) at 1 meter, no oil contamination.
Reliable & Stable
FEA-tested impeller with consistent air pressure over long runs. No belt, no gearbox, no coupling — zero transmission loss.
Easy Installation
Modular design, install in 30 minutes. Compact footprint (smallest 600×560×562mm). No special foundation required.
Smart Control
VFD with 485 communication, PLC integration, remote diagnostics, PT100 temperature protection. Variable speed on demand.
Full Ceramic Bearings
Every model from 1kW to 15kW ships with ceramic ball bearings — no cut corners. Heat-resistant, ultra-long service life.
H-Series Model Range
8 power options from 1.25kW to 15kW — matched to your air flow and pressure requirements.
| Model | Power | Air Flow | Pressure | Control |
|---|---|---|---|---|
| H1.25P | 1 kW | 500 m³/h | 9 kPa | Electronic |
| H2P | 1.5 kW | 600 m³/h | 12 kPa | VFD |
| H3P | 2.2 kW | 800 m³/h | 15 kPa | VFD |
| H5.5P | 4 kW | 1400 m³/h | 22 kPa | VFD |
| H7.5P | 5.5 kW | 1600 m³/h | 24 kPa | VFD |
| H10P | 7.5 kW | 1800 m³/h | 28 kPa | VFD |
| H15P | 11 kW | 2400 m³/h | 30 kPa | VFD |
| H20P | 15 kW | 2600 m³/h | 35 kPa | VFD |
Applications
PCB / LCD Drying
High-pressure air knife drying after PCB and LCD glass cleaning. Water stain-free surface.
Ultrasonic Cleaning
Post-rinse drying in ultrasonic cleaning lines. Stable high-pressure airflow removes surface water rapidly.
Auto Parts Cleaning
Drying blow-off after automotive component and metal stamping washing. Consistent pressure, no pressure drop.
Food & Pharma Packaging
Beverage and can line drying. Completely oil-free air, no contamination risk to food or pharma products.
Medical Devices
Low-noise oil-free drying for medical device clean rooms. Meets cleanroom environment requirements.
Wire & Cable
Air knife blow-off for wire and cable extrusion lines. Variable speed adapts to different line speeds.
Ready to Cut Your Energy Bills by 40–60%?
Send us your air flow and pressure requirements — we recommend the right model within 24 hours.
